Transparent DZ47 32A 1P+N Leakage protection Residual current Circuit breaker RCBO
DZ47LE-63 mini circuit breaker has novel structure,reliable,performance,high breaking capacity,pleasing outlook and items are adopted by high fireresistance and shockproof plastic,it mainly used in the buildiung office,house and similar building for illuminating at Ac 50Hz(60Hz),rated voltage below 415V,rated current below 63A,distribution circuit and equipment overload,short circuit protection.It can also be used for unfrequent switch over of the circuit under conditions.This product conforms to the requirement of GB 16917.
Characteristics
This Product confirms the requirement of IEC61009-1 and GB16917.1 standards
| Type | DZ47LE-63/1P+N | DZ47LE-63/2P | DZ47LE-63/3P | DZ47L3-63/3P+N three pole four line |
| Pole&line | single pole Two line | Two poles two line | Three pole four line | Four pole four line |
| Rated voltage Un(V) | 230 | | 230/400 | |
| Frame grade rated current Inm(A) | 32 | 50 | | |
| Rated voltage In(A) | 6A 10A 16A 20A 25A 32A 40A 50A 63A |
| Rated leakage non-operating current Ino(A) | 0.5ln |
| Breaking time | ≤0.1 |
| Rated short-circuit making and breaking | 6000 |
| capacity(cosf=0.7) | 4500v |
| Mechanical and electric life(time) Delay | 1.13In≥1h Norelease 1.45ln<1h Release 2.25ln1-60s Release |
| Mechanical and electric life(time) Inst | 5In≥0.15release 10In<0.15release |
